Wholesale High Quality LED Shoebox Lights, Walkways Lighting 130lm/w, Factory Direct Sales

ETL/cETL Listed, DLC 4.4 Premium Certified.
1-10V Dimming Optional.
Photocontrol Sensor For Dusk to Dawn Operation.
Built-in 10KV Surge Protector.
IP66 Waterproof Rated.
  • Overview
  • Applications
  • Download
  • Packing & Shipping


Product Description:

The SBAL LED area light is designed as a replacement for street lights and vapor lamps. It has a low-file design made of one-piece die-cast aluminum housing with UV-resistant polycarbonate optical lens. This LED area light delivers high lumens with efficacy up to 130 lumens per watt and long life for a more energy-efficient and low maintenance lighting solution IP66/IK09 design for harsh environ-menus from -22to 122 F. This LED area light is designed to slip-fit, round pole, square pole and trunnion(bracket)mount, the versatile mounting configurations offer simple installation. The type llI, IV, V light distribution makes it ideal for general outdoor and commercial area lighting in parking lots, office complexes, campuses, walkways, stadiums, squares and billboards, etc.

Specification:

Specifications

KLSBAL100-

XXXXXXXXXXX

KLSBAL150-

XXXXXXXXXXX

KLSBAL200-

XXXXXXXXXX

KLSBAL320-

XXXXXXXXXXX

Power Consumption(W) 100 150 200 320
Lumens Delivered (lm) 13000 19500 26000 41600
Efficacy (lm/W) 130 130 130 130
Input Voltage 100-277VAC 100-277VAC 100-277VAC 100-277VAC

General Features:


CRI: More than 70                                                                                            Certification: ETL/CETL, DLC Premium
Color Temperature: 3000K/4000K/5000K                                                        Life time: >50,000hrs
Power Factor: >0.9                                                                                           Housing:
Die-cast aluminum body(Bronze/Black). PC diffuse

Installation: SBAL-TA: Round Pole Mount, SBAL-TB: Square Pole Mount
Operating temperature: -30℃ up to 50℃(-22°F up to 122°F)

Environment: Damp/Wet locations                                                                  Warranty: 5 years
Lens: Polycarbonate Body & Diffuser                                                               Ingress Protection: IP66



Application:

- Wet areas                                             - Urban road
- Office complexes                                 - Highway
- Campuses                                            - Industrial area
- Walkways                                             - Sidewalk
- Stadiums                                              - Garden
- Squares                                                - School
- Billboards                                             - Residential area
- Commercial area                                  - Parking lots

Packing:

Packed in cartons, the same type of products are packed together or different products packaged together.

Transportation:

For LED lights export, our main modes of transportation are air and ocean, the transit time will be 4-10 days for air or 25-30 days for ocean.

International express includes 4 types: FedEx, DHL, TNT, UPS.

Domestic express includes SF, Sto, YTO, ZTO, Baishi, and Yunda Express, Transit time 3-5 days.
