High Power LED Street Lighting
thumb
thumb
thumb
thumb
thumb

The Best Quality And Performance CE RoHS IP66 Waterproof LED Street Lights, Lifespan Over 100,000 hrs, Contractor-Friendly Installation and Maintenance

CE, RoHS Certified.
DALI/1-10V Dimmable.
IP66 Waterproof Rated.
IK08 Impact Rating.
5 Yrs Warranty.
Up to 140lm/w.
L90 @ 100,000 hrs Ta =25°C.
Input Voltage : 90-305VAC.
Surge Protection Built in 10Kv.



  • Overview
  • Applications
  • Download
  • Packing & Shipping

Product Description:
CUBE is an LED luminaire that excels in optical performance, thermal management, compatibility, and serviceability, bringing an uncompromised outcome of efficiency, versatility, future-proofed for an optimized investment. CUBE demanding lighting requirements, being easy to install and maintain. It combines the latest LED light source with state-of-the-art design, achieving long life for both LEDs and drivers. The installation is simple and fast,  and the luminaire is easily upgradable on-site if required.

Key Benefits:
- Slim and elegant aesthetics
- Future-proof and upgradable on site
- Superior luminaire efficacy up to 140 lm/W
- Wide range of optics and lumen packages
- Advanced thermal management - Maximised savings on energy and maintenance costs
- Contractor-friendly installation and maintenance
- Up to M1 lighting class applications
- Up to G6 glare rating
- Dark sky friendly and no upward light
- Flexible and intelligent lighting control options
- Low windage and lightweight
- IP66 ingress protection
- 100% recyclable

Specification:
Code Power
Consumption
Nominal Size Net Lumen
Output
Weight Packing
KLCUBE060 60W 600mm x 301mm x 134mm 8400lm 7.8KG 620mm x 320mm x 154mm
KLCUBE080 80W 600mm x 301mm x 134mm 11200lm 8KG 620mm x 320mm x 154mm
KLCUBE100 100W 600mm x 301mm x 134mm 14000lm 8.2KG 620mm x 320mm x 154mm
KLCUBE120 120W 600mm x 301mm x 134mm 16800lm 8.5KG 620mm x 320mm x 154mm
KLCUBE150 150W 600mm x 301mm x 134mm 21000lm 12.8KG 620mm x 320mm x 154mm
KLCUBE180 180W 700mm x 360mm x 140mm 21600lm 13.2KG 720mm x 380mm x 160mm
KLCUBE200 200W 700mm x 360mm x 140mm 28000lm 13.2KG 720mm x 380mm x 160mm
KLCUBE240 240W 700mm x 360mm x 140mm 33600lm 13.2KG 720mm x 380mm x 160mm
KLCUBE270 270W 800mm x360mm x 140mm 37800lm 17.5KG 820mm x380mm x 160mm
KLCUBE320 320W 800mm x360mm x 140mm 44800lm 17.5KG 820mm x380mm x 160mm

General features:
Input Voltage : 90-305VAC                                          Driver Type: MW/PHILIPS/Inventronics
Colour Rendering Index >70Ra                                   Mounting Bracket: 76/60/50mm
Chip Brand : PHILIPS/CREE/Bridgelux                          Installation Height: 3-15m
Operating Temperature -35°C to 50°C                        Color Temperature: 3000K - 6500K
Glare Rating up to G6 (depending on lens)                 Optical Cover :Toughened flat glass
Lighting Regulation Mini Photocell • NEMA Socke
Post Top / Side Entry Tilt -10°, -5°, 0°, 5°, 10°
Material : High pressure die cast aluminium (Housing)


Applications:

- Wet areas                                             - Urban road
- Office complexes                                 - Highway
- Campuses                                            - Industrial area
- Walkways                                             - Sidewalk
- Stadiums                                              - Garden
- Squares                                                - School
- Billboards                                             - Residential area
- Commercial area                                  - Parking lots


Packing:

Packed in cartons, the same type of products are packed together or different products packaged together.

Transportation:

For LED lights export, our main modes of transportation are air and ocean, the transit time will be 4-10 days for air or 25-30 days for ocean.

International express includes 4 types: FedEx, DHL, TNT, UPS.

Domestic express includes SF, Sto, YTO, ZTO, Baishi, and Yunda Express, Transit time 3-5 days.
