(VFR) 4ft LED Vapor Tight Fixture

Easy-to-install and Elegant 4ft Vapor Tight Fixture

UL/cUL listed, DLC4.4 Premium, FCC, CE, RoHS.
IP65 Rated.
105-150lm/W.
0-10V dimming.
Microwave Motion Sensor for Bi-Level control.
90 mins emergency battery.
  • Overview
  • Applications
  • Download
  • Packing & Shipping


Product Description:

The vapor tight fixture is a cost-effective and energy-efficient alternative to traditional fluorescent tubes or strips light fixtures. Featuring a full-length, casketed polycarbonate lens and single-piece non-corrosive polycarbonate body, this vapor tight led is protected with an IP65 rating, sealed and casketed against dust, dirt, and humidity, making it ideal for both indoor and outdoor harsh environments applications, including utility lighting, parking garages, freezers and cold storage facilities, food processing, car washes, stairwell lighting and low bay lighting. Additionally, ceiling or surface mounted, this led tri proof light has an initial lumen range of 105-150LPW and features 0-10V dimming standards. As well, this model comes with a motion sensor for maximum energy savings as well as 90 mins emergency battery backup options.


Specification:

Specification Power consumption(W) Lumens Delivered (lm) Efficacy (lm/W) Certification
VFRA4F-XXXXP 60W 7800lm 130lm/w (Frosted)
150lm/w (Clear)
UL/cUL, DLC Premium
VFRB4F-XXXXP 40W 5200lm 130lm/w (Frosted)
150lm/w (Clear)
UL/cUL, DLC Premium
VFRC4F -XXXXP 40W 4200lm 105lm/w (Frosted)
130lm/w (Clear)
UL/cUL, DLC


General features:

Beam angle: 120°                                                                                                       CRI: 80

Housing: PC; VFRD4F-XXXXS: PC (5VA,f1)                                                                 Color Temperature: 3000K/4000K/5000K

Life time: 50,000h                                                                                                       Power Factor: >0.9

Input Voltage: 100-277VAC                                                                                        Installation: Surface Mount/ Chain/ J-Box Mounting

Operating temperature: -40℃ Up to 50℃ (-40℉up to122℉)                                   Environment: Wet locations

Warranty: 5 years                                                                                                       Driver Type : UL Driver
LED Type: LM80 SMD2835                                                                                         Material : Polycarbonate Body & Diffuser
Impact Rating: IK08



Applications:

Wet areas / Outside walkways / Warehouses / Storage areas / Industrial units / Farm buildings / Garages / Workshops / Stairwells / Factories / Car parks / Changing rooms


Packing:

Packed in cartons, the same type of products are packed together or different products packaged together.

Transportation:

For LED lights export, our main modes of transportation are air and ocean, the transit time will be 4-10 days for air or 25-30 days for ocean.

International express includes 4 types: FedEx, DHL, TNT, UPS.

Domestic express includes SF, Sto, YTO, ZTO, Baishi, and Yunda Express, Transit time 3-5 days.
