(VFF) Modern Version LED Tri Proof Light

Hot Sale Modern LED Tri Proof Light, Vapor Tight Fixture

CE, RoHS, ETL/cETL, FCC Certification.
130LM/W.
0-10V Dimming Standard.
Microwave Motion Sensor for Bi-Level Control.
90 mins Emergency Battery Backup.
5 Years Warranty.
  • Overview
  • Applications
  • Download
  • Packing & Shipping

Product Description:

The vapor tight fixture is a cost-effective and energy efficient alternative to traditional fluorescent tubes or strips light fixtures. Featuring a full-length, casketed polycarbonate lens and single piece non-corrosive polycarbonate body, this vapor tight led is protected with IP65 rating, sealed and casketed against dust, dirt, and humidity, making it ideal for both indoor and outdoor harsh environments applications, including utility lighting, parking garages, freezers and cold storage facilities, food processing, car washes, stairwell lighting and low bay lighting. Additionally, ceiling or surface mounted, this led tri proof light has an initial lumen range of 130-145LPW and features 0-10V dimming standards. As well, this model comes with a motion sensor for maximum energy savings as well as 90 mins emergency battery backup options.

   Specification:

Produce Code VFF040-XXXXP-XX
VFFXX-XXXXP-XX VFFHVXX-3CTXP
Power Consumption(W) 40W 40W/50W/60W adjustable 32W/40/50W adjustable
Lumens Delivered Frosted(lm) 5200lm 7800lm((60W) 6500lm(50W)

General Features:
Beam angle: 165*120°                                                                                      CRI: 80
Power Factor: >0.9                                                                                           Color Temperature : 3000K/4000K/5000K/3CCT adjustable

Installation: Surface Mount/Chain/Junction box                                             Efficacy (lm/W): 130lm/W (Frosted)

Operating temperature: -40℃ Up to 50℃ (-40℉up to122℉)                         Input Voltage: 100-277/120-347Vac
Driver Type: UL Driver                                                                                      Luminous Efficacy: up to 150lm/w(Clear lens)
LED Type: LM80 SMD2835                                                                               Material: Polycarbonate Body & Difuser
Rated Life: 50,000 hours                                                                                   Certificates: CE, RoHS, ETL/cETL, FCC

Applications:
Parking Garage / Cold Storage / Supermarket / Warehouses / Industrial units / Farm buildings / Workshops / Stairwells / Factories / Car parks / Changing rooms / Wet Locations

Packing:

Packed in cartons, the same type of products are packed together or different products packaged together.

Transportation:

For LED lights export, our main modes of transportation are air and ocean, the transit time will be 4-10 days for air or 25-30 days for ocean.

International express includes 4 types: FedEx, DHL, TNT, UPS.

Domestic express includes SF, Sto, YTO, ZTO, Baishi, and Yunda Express, Transit time 3-5 days.
