IP66 UFO High Bay Light, 130lm/W, LED Warehouse Lighting.

ETL/cETL listed for Wet Locations, FCC.
IP66 Waterproof Rated.
0-10V dimming.
Microwave motion sensor.
Glass lens or PC lens optional.
High heat dissipation design.
High efficient SMD LED chips.
  • Overview
  • Applications
  • Download
  • Packing & Shipping

Product Description:

The new generation of LED high bay light adopts the appearance of UFO, which makes it more futuristic, longer lifespan, lower maintenance and higher efficiency. Replace less-efficient traditional 500W metal halide bulb with a 35,000lms output at 250W LED. Slim body, lightweight no bulky heat sink, internal isolation high performance LED driver as well as LM80 LEDs, the LED high bay light can also work with 0-10V dimmer, brightness is adjustable as your desire. Preinstalled hook make it easy for a fast installation and come with an alternative sturdy U-bracket to mount the LED high bay light to wall or ceiling and adjust it to achieve expected emitting angle. It's simple to replace existing lights or make a new installation. The LED high bay light is ideal for commercial or industrial lighting, such as warehouses, factories, gyms, supermarkets, stadiums, retail spaces, workshops, industrial areas, garages, etc.


Specification Wattage(W) Lumens Delivered (lm)
KLHB10WCS 100W 14000lm
KLHB150WCS 150W 21000lm
KLHB200WCS 200W 28000lm
KLHB240WCS 250W 35000lm

General features:
Efficacy:  140lm/W                                                                                            CRI:  >80

Color Temperature:  3000K/4000K/5000K/5700K                                            Beam Angle:  120°

Life time:  >50,000 hours                                                                                  Power Factor:  0.98at 100VAC 0.90 at 277VAC

Input Voltage:  100-277VAC                                                                             Housing:  Die-cast aluminum body(Black). 120° Glass diffuse 60°PC Lens

Installation:  Via cable& pendant suspension & surface mounted                  Operating temperature:  -30℃ Up to 50℃ (-22℉up to122℉)

Certification:  ETL/cETL, FCC                                                                              Warranty:  5 Years


Wet areas / Warehouses / Factories / Gyms / Supermarkets / Stadiums / Workshops / Retail spaces / Industrial areas / Garages / Cold storages.


Packed in cartons, the same type of products are packed together or different products packaged together.


For LED lights export, our main modes of transportation are air and ocean, the transit time will be 4-10 days for air or 25-30 days for ocean.

International express includes 4 types: FedEx, DHL, TNT, UPS.

Domestic express includes SF, Sto, YTO, ZTO, Baishi, and Yunda Express, Transit time 3-5 days.
